Product Description
GP Elite Advanced Options
*Assembly Required*
NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.
________________________________________________
37hz
| Box External Dimensions Width x Height x Depth |
30.00" x 12.50" x 18.08" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.45 ft3 |
| Tuning Frequency | 37 Hz |
| Port Area | 33.00 inch2 |
| Port Inlet Width x Height |
3.00" x 11.00" |
| Port Length | 19.48" |
________________________________________________________________________________________________
35hz
|
Box External Dimensions |
30.00" x 12.50" x 18.50" |
|
Material Thickness |
0.75" |
|
Net Internal Volume |
2.45 ft3 |
|
Tuning Frequency |
35 Hz |
|
Port Area |
33.00 inch2 |
|
Port Inlet |
3.00" x 11.00" |
|
Port Length |
22.59" |
________________________________________________________________________________________________
33hz
|
Box External Dimensions |
30.00" x 12.50" x 19.00" |
|
Material Thickness |
0.75" |
|
Net Internal Volume |
2.45 ft3 |
|
Tuning Frequency |
33 Hz |
|
Port Area |
33.00 inch2 |
|
Port Inlet |
3.00" x 11.00" |
|
Port Length |
26.29" |
________________________________________________________________________________________________
31hz
|
Box External Dimensions |
30.00" x 12.50" x 19.64" |
|
Material Thickness |
0.75" |
|
Net Internal Volume |
2.45 ft3 |
|
Tuning Frequency |
31 Hz |
|
Port Area |
33.00 inch2 |
|
Port Inlet |
3.00" x 11.00" |
|
Port Length |
30.72" |
________________________________________________________________________________________________
29hz
| Box External Dimensions Width x Height x Depth |
30.00" x 12.50" x 20.44" |
| Material Thickness | 0.75" |
| Net Internal Volume | 2.45 ft3 |
| Tuning Frequency | 29 Hz |
| Port Area | 33.00 inch2 |
| Port Inlet Width x Height |
3.00" x 11.00" |
| Port Length | 36.11" |
