Product Description
GP Elite Advanced Options
Every GP Elite enclosure is 100% designed to order per subs you are using and comes standard with bracing everywhere and 45. If you are looking for an extremely high end cabinet, look no further.
Any dimensions can be altered, let us know your max dimensions in the order notes, or leave us a note on the order to have us call you to go over anything, be sure to note your vehicle.
NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.
*Assembly Required*
NOTE* Tuning will change the enclosure sizes slightly.
_____________________________________
37hz
Box External Dimensions Width x Height x Depth |
28.00" x 16.50" x 19.74" |
Material Thickness | 0.75" |
Net Internal Volume | 3.50 ft3 |
Tuning Frequency | 37 Hz |
Port Area | 47.25 inch2 |
Port Inlet Width x Height |
3.15" x 15.00" |
Port Length | 18.18" |
_____________________________________
35hz
Box External Dimensions Width x Height x Depth |
28.00" x 16.50" x 20.20" |
Material Thickness | 0.75" |
Net Internal Volume | 3.50 ft3 |
Tuning Frequency | 35 Hz |
Port Area | 47.25 inch2 |
Port Inlet Width x Height |
3.15" x 15.00" |
Port Length | 21.30" |
_____________________________________
33hz
Box External Dimensions Width x Height x Depth |
28.00" x 16.50" x 20.77" |
Material Thickness | 0.75" |
Net Internal Volume | 3.50 ft3 |
Tuning Frequency | 33 Hz |
Port Area | 47.25 inch2 |
Port Inlet Width x Height |
3.15" x 15.00" |
Port Length | 25.00" |
_____________________________________
31hz
Box External Dimensions Width x Height x Depth |
28.00" x 16.50" x 21.47" |
Material Thickness | 0.75" |
Net Internal Volume | 3.50 ft3 |
Tuning Frequency | 31 Hz |
Port Area | 47.25 inch2 |
Port Inlet Width x Height |
3.15" x 15.00" |
Port Length | 29.45" |
_____________________________________
29hz
Box External Dimensions Width x Height x Depth |
28.00" x 16.50" x 22.36" |
Material Thickness | 0.75" |
Net Internal Volume | 3.50 ft3 |
Tuning Frequency | 29 Hz |
Port Area | 47.25 inch2 |
Port Inlet Width x Height |
3.15" x 15.00" |
Port Length | 34.85" |
Product Videos
Custom Field
Product Reviews
1 Review Hide Reviews Show Reviews
-
Awesome enclosure
Ordered this glue and screw enclosure for my RS Platinum 15. Gave some dimensions I needed it to fit in. Came out perfect. Box looks amazing. Will definitely be ordering my next one from GP
