GP ELITE Single 15" High Output Glue it & Screw It Sub Enclosure
GP Elite Advanced Options
Every GP Elite enclosure is 100% designed to order per subs you are using and comes standard with bracing everywhere and 45. If you are looking for an extremely high end cabinet, look no further.
Any dimensions can be altered, let us know your max dimensions in the order notes, or leave us a note on the order to have us call you to go over anything, be sure to note your vehicle.
*Assembly Required*
NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.
_____________________________________
37hz
| Box External Dimensions Width x Height x Depth |
32.00" x 16.50" x 20.04" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 37 Hz |
| Port Area | 60.00 inch2 |
| Port Inlet Width x Height |
4.00" x 15.00" |
| Port Length | 20.05" |
_____________________________________
35hz
| Box External Dimensions Width x Height x Depth |
32.00" x 16.50" x 20.59" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 35 Hz |
| Port Area | 60.00 inch2 |
| Port Inlet Width x Height |
4.00" x 15.00" |
| Port Length | 23.52" |
_____________________________________
33hz
| Box External Dimensions Width x Height x Depth |
32.00" x 16.50" x 21.26" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 33 Hz |
| Port Area | 60.00 inch2 |
| Port Inlet Width x Height |
4.00" x 15.00" |
| Port Length | 27.63" |
_____________________________________
31hz
| Box External Dimensions Width x Height x Depth |
32.00" x 16.50" x 22.09" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 31 Hz |
| Port Area | 60.00 inch2 |
| Port Inlet Width x Height |
4.00" x 15.00" |
| Port Length | 32.57" |
_____________________________________
29hz
| Box External Dimensions Width x Height x Depth |
32.00" x 16.50" x 23.15" |
| Material Thickness | 0.75" |
| Net Internal Volume | 4.00 ft3 |
| Tuning Frequency | 29 Hz |
| Port Area | 60.00 inch2 |
| Port Inlet Width x Height |
4.00" x 15.00" |
| Port Length | 38.57" |
-
100% Legit!
Let's just say I was skeptical if it would survive the ride without getting the corners crushed. But it made it. Went with the 12x24 plexi window with the Cadillac emblem engraved and I'm floored. Cant say how it sounds as I'm still waiting on my sub (FI 3.5 Neo 15) but if it sounds as good as the craftsmanship I'll be thoroughly happy. GP customer for life!
-
Exactly as described
It was well packaged and easy to assemble for someone who has experience with woodworking. The box sounds great with my system.
