Sundown Audio U Series 10" v.2 2000 RMS

2000w RMS *Wattage Ratings Have Been Increased By Sundown Audio: Packaging May Display Prior Wattage Ratings Until New Shipment Arrives*

Product Description

• Features (U-10 / 12 / 15 / 18)

  • Black Aluminum 3" voice coil former for superior heat dissipation
  • High Temperature Round-Wire CCAW voice coil with high-temp black adhesive
  • Double stitched surround
  • Heavy duty cast basket
  • Spring loaded terminals accept up to 8 gauge
  • Stitched-on double-XL tinsel leads
  • Rear vented pole piece
  • Rear drilled gap-venting
  • Innovative high-velocity cast aluminum vented frame spacer ring
  • Magnet ID shorting ring
  • Top-Plate Cooling Channels
  • Cast Aluminum surround bolt-on rings
  • Optimized for small ported or bandpass enclosures



  U-10

  T/S SPECS	U 10" D2	U 10" D4
  RE (Ohms)	3.8	6.1
  FS (Hz)	48.5	41.1
  VAS (L)	8.3	11.5
  Qes	0.35	0.39
  Qms	3.20	3.21
  Qts	0.32	0.35
  Le (mH)	2.56	3.71
  BL (NA)	26.8	29.7
  Mms (Grams)	216.3	219.7
  Cms (uM/N)	0.05	0.07
  Sens (dB @ 1w/1m)	86.2db	84.9db

  U-10

  Sealed Enclosure	0.5 cu ft
  Ported Enclosure	1.0 cu ft
  Recommended Tuning	35Hz
  Recommended Port Area	16 sq in
  Displacement	0.21 cu ft
  Depth	7.007"
  Outside Diameter	10.94"
  Cut-Out	9.17"
